Personal Light Line 25m_4BDL-0251
-
Payment
O/A , T/T
-
MOQ
100 Set
-
Supply Ability
10,000 Set per One-Time
-
Supply Details
Customization In Short Supply Limited goods
Negotiable / Depends on quantity
-
Country of sale
Asia, World Wide, Americas, Europe, Middle East
-
PRICE
-
FOB
Depend on quantity
-
ITEM SPECIFICS
-
Brand
Model 4BDL-02514BDREAM
-
origin
Republic of Korea
-
Size(Capacity)
H142 x W138 x D93mm
-
Weight
1kg ± 0.1kg
-
Color
Orange
PRODUCT DESCRIPTION
Personal Light Line 25m
Key Features
1. Dual signal communication system between main body and handpiece
2. Three lighting modes: steady, flashing (1/sec), emergency visual x-alert (3/sec)
3. Rechargeable lithium-ion battery with low self-discharge (10 years if unused after full charge)
4. High durability and waterproof (Main body: IP66 / Line: IPx8)
5. Heat resistant up to 120°C – suitable for firefighting environments
6. Automatic x-alert sound with visual flash in emergency mode
7. Ergonomically designed with shoulder strap and handle for field deployment
2. Three lighting modes: steady, flashing (1/sec), emergency visual x-alert (3/sec)
3. Rechargeable lithium-ion battery with low self-discharge (10 years if unused after full charge)
4. High durability and waterproof (Main body: IP66 / Line: IPx8)
5. Heat resistant up to 120°C – suitable for firefighting environments
6. Automatic x-alert sound with visual flash in emergency mode
7. Ergonomically designed with shoulder strap and handle for field deployment
Advantages
1. Self-manufactured for quality assurance
2. 5-year product warranty (except EL Wire)
3. Designated as Excellent Procurement Product (PPS)
4. Patents registered in Korea, CE certified
2. 5-year product warranty (except EL Wire)
3. Designated as Excellent Procurement Product (PPS)
4. Patents registered in Korea, CE certified
Components
1. Main body with EL wire
2. Charging adapter (LED status indicator: Red = Charging / Green = Fully Charged)
3. Handpiece (emergency communication unit)
4. Shoulder strap
5. User manual
2. Charging adapter (LED status indicator: Red = Charging / Green = Fully Charged)
3. Handpiece (emergency communication unit)
4. Shoulder strap
5. User manual
How to Use
1. Fully charge the device before use. Red = Charging / Green = Charged
2. Press the power button to activate the device.
3. Use the mode button to switch between constant light, flashing, and emergency signal.
4. In emergencies, press the emergency button on the handpiece (1 sec) to activate flashing; press again for emergency visual x-alert.
5. After use, turn off the power and wind the light line clockwise for storage.
2. Press the power button to activate the device.
3. Use the mode button to switch between constant light, flashing, and emergency signal.
4. In emergencies, press the emergency button on the handpiece (1 sec) to activate flashing; press again for emergency visual x-alert.
5. After use, turn off the power and wind the light line clockwise for storage.
Cautions
1. Do not use for purposes other than evacuation guidance.
2. Do not disassemble or arbitrarily modify the product.
3. If a burning smell or overheating occurs, discontinue use and contact the manufacturer.
4. Avoid water immersion and long-term storage in damp environments.
5. Do not expose to solvents or strong chemicals – wipe with a soft cloth if necessary.
6. Ensure the EL wire cover is not damaged to prevent electric shock or malfunction.
7. Store in a cool, dry place (recommended storage temperature: -20°C to +20°C).
8. Avoid storing near flammable materials or direct sunlight.
2. Do not disassemble or arbitrarily modify the product.
3. If a burning smell or overheating occurs, discontinue use and contact the manufacturer.
4. Avoid water immersion and long-term storage in damp environments.
5. Do not expose to solvents or strong chemicals – wipe with a soft cloth if necessary.
6. Ensure the EL wire cover is not damaged to prevent electric shock or malfunction.
7. Store in a cool, dry place (recommended storage temperature: -20°C to +20°C).
8. Avoid storing near flammable materials or direct sunlight.
Specification
| Model name | 4BDL-0251 |
| Dimension | H142 x W138 x D93mm |
| EL wire Length / Diameter | 25m ± 0.5m / 3.0mm ± 0.3mm |
| Tensile Strength | 2200n/mm2 |
| Luminance | 30cd/m2 |
| Heat Resistance | 120°C 30min |
| Batt Power | DC 7.2V 5.2A |
| Operation Time | Light on mode (360min), Light Blinking mode1 (600min), Light Blinking mode2 (650min) |
| Dustproof / Waterproof | IP66 |
| Adapter | 110V/220V, 50/60Hz, 8.4V, 2A (Safety Certification No. HU10539-12050) |
| Certified Excellent Procurement, CE Certification |
